| 원래 장소 | 중국 |
| 브랜드 이름 | GUANGLIJIN |
| 인증 | CE Certificate |
| 모델 번호 | G5-330 터닝 및 밀링 가공 센터 |
| G5-330 Machine Center | |||
| No. | Item | Details | |
| 1 | B axis reducer | DD motor | Rated torque 20n.m, Max. torque 60n.m, |
| 2 | C axis reducer | DD motor | Rated torque 436n.m, Max. torque 1200n.m, |
| 3 | Transmission components | Rexroth, Germany | Repeatability: +/-0.002m |
| 4 | Operation | SYNTEC system | 220MA-10.4 inch screen operation box |
| 5 | Servo motor | 750w | |
| 6 | Spindle | electric | 8kw, max. speed 36000 rpm water cooling with flow-alarm |
| 7 | Tool magazine | servo-drive | Up to 21 tools |
| 8 | Tool calibration | auto setting | speed 50-200mm/min, accuracy 0.002mm |
| 9 | Tool holder | HSK E32 | |
| 10 | Collet chuck | ER-20 | |
| 11 | Accuracy compensation | Linear encoder from Heidenhain, Germany | accruacy: +/-2um, max. interpolation errors +/-0.1um, with atmoseal protection |
| 12 | Lubrication | Timing automatic oiling | |
| 13 | Working flatness | +/-0.002mm | |
| 14 | X axis stroke | 200mm | |
| 15 | Y axis stroke | 380mm | |
| 16 | Z axis stroke | 280mm | |
| 17 | Body weight | 3 tons | |
| 18 | Front door | sliding door | |
| 19 | Layout (mm) | main body | 1710 width*1220 depth*2100 height |
| 20 | Power requirement | three-phase | 380v/50hz |
| 21 | Optional configuration | auto rod holder | max. dia. 25mm |
| 22 | manual chuck | ||
| 23 | auto chuck | can cooperate with robot | |
| 24 | laser tool calibration | Renishaw, UK | |
| 25 | Nodular cast iron, gantry type milling, regular milling diameter is 200mm, max. milling size can be 300*300mm; need constant temperature workshop to ensure linear encoder accuracy. |
||
Technical support
Installation
Training
Maintenance
Troubleshooting
Software upgrade
Fumigation wooden case by sea or by air
Q: Are you a dealer or manufacturer?
A: We, Guanglijin, is a manufacturer of CAD/CAM CNC machine with over 20 years experience.
Q: Where are you from?
A: We are from Shenzhen China, one of the most creative city in the world.
Q: Do you provide overseas support or service?
A: Yes, we have a technican team which can travel abroad to do global service and support.
Q: Does this machine come with any certification?
A: Our machines are CE certificated.
